1. The key inspecting part is imported from Germany with long service life.
2. Fast analyzing for new type of terminal crimping.
3. The technology of terminal cutting and grinding is same ensure its uniformity.
4. High working efficiency to save the working time.
5. The high precision ball screw transmission technology from Japan Misumi to ensure the cutting precision.
6. The high precision Z shaft micro-grinding technology from Japan Misumi to ensure grinding precision to 0.01mm.
7. The super thin blade cutting technology from Germany to avoid the deformation of terminal by cutting.
8. High measuring precision, good stability, strong anti-interference ability easy for maintenance .
9. Its data collecting system for rotary speed to use relative rotary speed for terminals in different diameters.
10. It is equipped with micro adjusting clamping module for terminal (Scale: 0.01mm)
| Terminal cutting range | 0.01-33.62mm2 |
| Cutting speed | 0-4000 rotation/minute (adjustable) |
| Abrasive paper for metallographic | 1200# |
| Cutting blade size | 150mm x 0.5mm |
| Microscope | 0.7X-4.5X (continuous X zooming lens, it could choose 3 mesh ) |
| Total zoom rate | 16-320X |
| Working temperature | -5ºC- 40ºC |
| Air pressure | 80 - 106 KPa |
| Power supply | 220V / 50 Hz |
| Weight | 30kg |
| Dimensions | 475x329x300 mm |
